PW183RA
Universal 32 Watt (IEEE802.3af Non-Compliant)
PoE Plus Gigabit
For the most current data and application support visit www.slpower.com
Ault Part Number
PW183RA4800_01
Output
Voltage
48 V
Min
0.00 A
Output Currents
Max
0.67 A
Max
Watts
32 W
Ripple
Vp-p max.
480 mV
Ault Part Number Key
PW183
R
A
48
00
_
01
Product
Manufacturing
Design
Voltage
Connector
Input
Standard
Family
Name
Location
(volume dependent)
Revision
Changes
DC
Model Type
Configuration/
Model Type
(no modifications
or special packaging)
Input Configuration
Pin Connections
e United United Australian
Kingdom (E) w/ground
(G) C14 (N)
(G)
IEC320 Shaver
Australian
Kingdom (E)
(F)
IEC320
Shaver
C8
(N)
w/o ground
C18
(Q)
N. America/
Japan
(B)
Europe
(M)
United
Kingdom
(G)
Australian
(E)
Shaver
C8
(N)
Specify the Input Configuration Code in your order.
General Specifications (continued from p. 1)
87654321
87654321
MTBF
Weight
(excluding cord)
100,000 Calculated Hours
7 Ounces, 200 Grams
J2
(P ower and Data Out)
J1
(Data In)
Case and Dimension
5.24L x 2.13W x 1.42H (in)
133.0L x 54.0W x 36.0H (mm)
(Rear of Unit)
Case Material
Black 94V0
Polycarbonate
PoE Gigabit Pin-out Connections:
Cord and Connectors
Dual RJ45 jacks built into
Data
POWER (+)
Pins 4/5 (Data + PWR)
the enclosure
Data
Pins 1/2 (Data Only)
Personalized PoE
Data
Pins 3/6 (Data Only)
Options (additional costs may apply):
? Custom label artwork
Data
POWER (-)
Pins 7/8 (Data + PWR)
? Custom agency approvals available
Note:
= Transformer
? Surge protection (Input & Output)
? Mounting bracket
? Custom PoE modifications
SL Power Electronics Corp ? 6050 King Drive ? Ventura, CA 93003 ? Phone:805.486.4565 ? Fax:805.487.8911 ? Email:info@slpower.com ? www.slpower.com
Data Sheet ? 2007 SL Power Electronics Corp. The information and specifications contained in this data sheet are believed to be correct at time of publication.
However, SL Power accepts no responsibility for consequences arising from reproduction errors or inaccuracies. Specifications are subject to change without notice.
Rev.12/21/07
